2007-18 Jeep JK Body Mount Tire Carrier TC-1

SKU TCSTTB-01
Original price $ 689.99 - Original price $ 689.99
Original price
$ 689.99
$ 689.99 - $ 689.99
Current price $ 689.99

The DV8 Jeep Wrangler JK Body Mounted Tire Carrier provides a high clearance tire mounting solution that is all about function.

Key Features:

  • 1-3/4" diameter steel tubing allows for a large array of tube clamps for mounting aftermarket accessories like Hi-Lift Jacks, LED Lights etc.
  • Mounts to the body at 4 points which allows for a strong, rattle free construction.
  • The latching system uses hitch pins for excellent security and strength
  • This carrier can be run with ANY aftermarket bumper for the JK
  • Holds the tire tighter to the body for better departure angles
  • Will fit any bolt pattern wheel
  • Includes a license plate relocation bracket and a cover for the old license plate mount
  • The DV8 Dimple Dye plates are removable
  • Comes powder coated DV8 textured black
  • Will work with aftermarket quarter panel guards
  • Our unique cam style adjustment makes adjusting the tire carrier simple and easy
  • Accommodates up to a 42" Spare tire

Click Here For Install Instructions

**Installation requires some drilling**

**Will accommodate up to a 13.5" wide tire**

**Will not work with OEM wheel due to wheel offset

Install Manual

Fitment
 MODEL YEARS
Jeep Wrangler JK 2007-2018
Quality Guaranteed

We are confident in our products and that they will satisfy your needs, however we realize that there are cases where a product may arrive damaged or defective. Our goal is for our customers to be happy. If you are not satisfied with your purchase of one of our products we will assist you in getting refunded* or exchanged for another product.

Customer Reviews

Based on 2 reviews
100%
(2)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
S
Stacey Rhodes
Dent

I love this but took it out of the box today and had a nice dent. Waiting for a response

T
Tom Bovee
Great concept poor engineering

First off the tire carrier is great looking, it adds a lot to my JK build. The fit up is horrible. I saw a couple install videos that cautioned me on buying the TC1. I thought you would improve your product after you have been told about mounting issues. I’m running 37 13.5 tires on 20” rims with a negative 44 offset. The tire is pressed against the tailgate and I’ve air it down to 12lbs. It’s so tight I had to clamp the pin side mount to get it to touch the body. The pin side bottom hole is useless as it is to low to the underside body panel to put a bolt into. You have been made aware of this a few times. Raise the hole in the mount. Also the backing plate will not fit for the same reason. Also alignment of the top pin holes will always be off because of the curve of the body panel. Either add some length to the top arm, 1/2 “ or put a cam bolt in the bottom hinge, that allows a forward or backwards adjustment. Basically a 180 of the top cam bolt. If you do fab up that style bottom hinge I want one. Also what size nut is on the wing nut? I want another to put on the inside to tighten the poly cone to my rim. The cone is about an inch away from making contact with my rim.
